Product Summary

The AD818 is a low cost, video op amp optimized for use in
video applications which require gains equal to or greater than
+2 or –1. The AD818 low differential gain and phase errors,
single supply functionality, low power and high output drive
make it ideal for cable driving applications such as video cam-
eras and professional video equipment.
With video specs like 0.1 dB flatness to 55 MHz and low differ-
ential gain and phase errors of 0.01% and 0.05
°, along with
50 mA of output current, the AD818 is an excellent choice for
any video application. The 130 MHz 3 dB bandwidth (G = +2)

Parametrics

AD818AR Datasheet (PDF) - Analog Devices - Low Cost, Low Power Video Op Amp

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AD818AR-REEL7
AD818AR-REEL7

IC VIDEO OPAMP LP 8-SOIC
Data Sheet
0-750: $1.78
AD818ARZ-REEL7
AD818ARZ-REEL7

IC VIDEO OPAMP LP 8-SOIC T/R
Data Sheet
0-750: $1.63
AD818ARZ-REEL
AD818ARZ-REEL

IC VIDEO OPAMP LP 8-SOIC T/R
Data Sheet
0-2500: $1.45
AD818ARZ
AD818ARZ

IC VIDEO OPAMP LP 8-SOIC
Data Sheet
0-1: $3.04
1-10: $2.71
10-100: $2.23
100-250: $2.01
250-500: $1.80
500-1000: $1.52
1000-2500: $1.45
AD818AR-REEL
AD818AR-REEL
Analog Devices Inc
IC VIDEO OPAMP LP 8-SOIC T/R
Data Sheet
1-2500: $1.59
AD818AR-EBZ
AD818AR-EBZ

BOARD EVAL FOR AD818AR
Data Sheet
0-1: $14.38
AD818AR
AD818AR

IC VIDEO OPAMP 130MHZ LP 8-SOIC
Data Sheet
0-98: $2.67
