Product Summary
The AD8313 is a complete multistage demodulating logarithmic amplifier that can accurately convert an RF signal at its differ-ential input to an equivalent decibel-scaled value at its dc output. The AD8313 maintains a high degree of log conformance for signal frequencies from 0.1 GHz to 2.5 GHz and is useful over the range of 10 MHz to 3.5 GHz. The nominal input dynamic range is –65 dBm to 0 dBm (re: 50 Ω), and the sensitivity can be increased by 6 dB or more with a narrow-band input impedance matching network or a balun. Application is straightforward, requiring only a single supply of 2.7 V to 5.5 V and the addition of a suitable input and supply decoupling. Operating on a 3 V supply, its 13.7 mA consumption (for TA = 25°C) is only 41 mW. A power-down feature is provided; the input is taken high to initiate a low current (20 μA) sleep mode, with a threshold at half the supply voltage.
Parametrics
AD8313ARMZ Datasheet (PDF) - Analog Devices - 0.1 GHz to 2.5 GHz 70 dB Logarithmic Detector/Controller
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 AD8313ARMZ |
|
IC LOGARTIHMIC AMP 70DB 8-MSOP |
Data Sheet |
|
|
||||||||||||||||
|
AD8313ARMZ-REEL |
|
IC LOG DETECTOR/CTRLR 8MSOP |
Data Sheet |
|
|
||||||||||||||||
|
AD8313ARMZ-REEL7 |
|
IC LOG DETECTOR/CTRLR 8-MSOP TR |
Data Sheet |
|
|
||||||||||||||||
