Product Summary

PAL B, D, G, H, I, M, N and NTSC M modes, YCrCb
4:2:2 data is input via the CCIR-656 compatible pixel port at a
27 MHz Data Rate. The pixel data is demultiplexed to from
three data paths. Y typically has a range of 16 to 235, Cr and
Cb typically have a range of 128 ± 112; however, it is possible
to input data from 1 to 254 on both Y, Cb and Cr. The
ADV7175A/ADV7176A supports PAL (B, D, G, H, I, N, M)
and NTSC (with and without Pedestal) standards. The appropriate
SYNC, BLANK and Burst levels are added to the
YCrCb data. Macrovision antitaping (ADV7175A only),
closed captioning and teletext levels are also added to Y, and
the resultant data is interpolated to a rate of 27 MHz. The
interpolated data is filtered and scaled by three digital FIR
filters.
The

Parametrics

 Analog Devices - High Quality, 10-Bit, Digital CCIR-601 to PAL/NTSC Video Encoder

Features

 Analog Devices - High Quality, 10-Bit, Digital CCIR-601 to PAL/NTSC Video Encoder

Diagrams
