Product Summary
Mitsubishi Intelligent Power Modules
are isolated base modules designed
for power switching applications
operating at frequencies to
20kHz. Built-in control circuits provide
optimum gate drive and protection
for the IGBT and free-wheel
diode power devices.
Parametrics
Ratings Symbol PM10CSJ060 Units
Power Device Junction Temperature Tj -20 to 150 °C
Storage Temperature Tstg -40 to 125 °C
Case Operating Temperature TC -20 to 100 °C
Mounting Torque, M4 Mounting Screws — 0.98 ~ 1.47 N · m
Module Weight (Typical) — 60 Grams
Supply Voltage Protected by OC and SC (VD = 13.5 - 16.5V, Inverter Part) VCC(prot.) 400 Volts
Isolation Voltage (Main Terminal to Baseplate, AC 1 min.) Viso 2500 Vrms
Features
Features:
u Complete Output Power
Circuit
u Gate Drive Circuit
u Protection Logic
– Short Circuit
– Over Current
– Over Temperature
– Under Voltage
