EDD1216AJTA-5B-E Datasheet (PDF) - Elpida Memory - 128M bits DDR SDR

Parametrics

? Density:  128M bits
? Organization
?  2M words × 16 bits × 4 banks
? Package:  66-pin plastic TSOP (II)
?  Lead-free (RoHS compliant)
? Power supply:  VDD, VDDQ = 2.5V ± 0.2V
? Data rate:  400Mbps/333Mbps/266Mbps (max.)
? Four internal banks for concurrent operation
? Interface:  SSTL_2
? Burst lengths (BL): 2, 4, 8
? Burst type (BT):
?  Sequential (2, 4, 8)
?  Interleave (2, 4, 8)
? /CAS Latency (CL): 2, 2.5, 3

Features

Features
? Double-data-rate architecture; two data transfers per
clock cycle
? The high-speed data transfer is realized by the 2 bits
prefetch pipelined architecture
? Bi-directional data strobe (DQS) is transmitted
/received with data for capturing data at the receiver
? Data inputs, outputs, and DM are synchronized with
DQS
? DQS is edge-aligned with data for READs; centeraligned with data for WRITEs
? Differential clock inputs (CK and /CK)
? DLL aligns DQ and DQS transitions with CK
transitions
? Commands entered on each positive CK edge; data
and data mask referenced to both edges of DQS
? Data mask (DM) for write data
